Measure to be sure you can install the gate to the post with approximately
a 2" gap from the ground to the bottom of the gate. Align the rails on
the gate to the rails on the fence panels.
Hang the gate between the posts. Use a 5/8" spacer between the
gate and the posts (fig. 10). Secure in place with shims under the gate
or clamp the gate to the post. Make sure the gate is level and square.
Attach hinge brackets to the gate post with the provided screws
(fig. 11).
Remove any clamps and shims. Attach latch using screws provided
(fig. 12).
Install a post cap on each post using PVC cement or an exterior adhesive.
NOTE: The gate latch is designed to be used on the left- or right-hand
side of the gate, depending on customer preference or design. The
latch is assembled and ready to be installed on the right-hand side of
the gate. If you desire to switch the latch, follow these simple steps:
• Remove the 2 shoulder bolts and spring
• Change the orientation of the striker
• Reattach the spring and insert the shoulder bolts
• Shoulder bolts must be fully tightened. Thread-locking adhesive
is recommended.
Dig post hole for the hinge post 18" to 24" in diameter and 36" to 42"
deep (depending on local ordinance or expected frost depth in winter).
We recommend that you insert a piece of 4x4 treated lumber to support
the gate hinge post (fig. 9).
Check measurement of gate. Actual width of the gate is 41-1/2".
The inside post-to-post dimension is 42-3/4". This will give you a
5/8" gap on both sides of the gate to the posts. DOUBLE-CHECK
ALL MEASUREMENTS!
Installing the Gate
Digging Post Holes
fig. 9
fig. 10
fig. 11 fig. 12
©2014 Universal Forest Products, Inc. All rights reserved.
2801 E. Beltline NE, Grand Rapids, MI 49525 800.332.5724 7807_7/14
www.ufpi.com
THE DIAGRAMS AND INSTRUCTIONS IN THIS BROCHURE ARE FOR ILLUSTRATION PURPOSES ONLY AND ARE NOT MEANT TO REPLACE A LICENSED PROFESSIONAL. ANY CONSTRUCTION OR
USE OF THE PRODUCT MUST BE IN ACCORDANCE WITH ALL LOCAL ZONING AND/OR BUILDING CODES. THE CONSUMER ASSUMES ALL RISKS AND LIABILITY ASSOCIATED WITH THE
CONSTRUCTION OR USE OF THIS PRODUCT. THE CONSUMER OR CONTRACTOR SHOULD TAKE ALL NECESSARY STEPS TO ENSURE THE SAFETY OF EVERYONE INVOLVED IN THE PROJECT,
INCLUDING, BUT NOT LIMITED TO, WEARING THE APPROPRIATE SAFETY EQUIPMENT. EXCEPT AS CONTAINED IN THE WRITTEN LIMITED WARRANTY, THE WARRANTOR DOES NOT
PROVIDE ANY OTHER WARRANTY, EITHER EXPRESS OR IMPLIED, AND SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING CONSEQUENTIAL DAMAGES.
